Normal size
|
As supplied(mm)
|
After recovered(mm)
|
Standard length(m)
|
|
(mm)
|
(inch)
|
Inside diameter(min.)
|
Inside diameter(Max.)
|
Wall thickness(mm)
|
Adhesive Thickness(mm(nom.)
|
|
19/6
|
3/4
|
19
|
6
|
3.05±0.3
|
1.35
|
1.22
|
|
25/8
|
1
|
25
|
8
|
3.05±0.3
|
1.35
|
1.22
|
|
33/8
|
11/4
|
33
|
8
|
3.05±0.3
|
1.35
|
1.22
|
|
40/12
|
11/2
|
40
|
12
|
3.05±0.3
|
1.35
|
1.22
|
|
55/16
|
2
|
55
|
16
|
3.05±0.3
|
1.35
|
1.22
|
|
65/19
|
21/2
|
65
|
19
|
3.05±0.3
|
1.35
|
1.22
|
|
75/22
|
3
|
75
|
22
|
3.05±0.3
|
1.35
|
1.22
|
|
100/30
|
4
|
100
|
30
|
3.05±0.3
|
1.35
|
1.22
|
Special size, cut pieces are available on request.
Halogen free heat shrinkable adhesive-lined tubing is available on request.
|
Property
|
Test Method
|
Typical Data
|
|
Tensile strength
|
ASTM D 2671
|
14MPa (min.)
|
|
Tensile strength after aging(158℃, 168hrs)
|
ASTM D 2671
|
Remains 70%
|
|
Elongation at break
|
ASTM D 2671
|
300% (min.)
|
|
Elongation at break after aging (158℃, 168hrs)
|
ASTM D 2671
|
100% (min.)
|
|
Longitudinal shrinkage
|
UL 224
|
0 to -10%
|
|
Heat shock
|
250℃, 4hrs.
|
No cracking, no dropping
|
|
Cold bend (-30℃,1hr.)
|
ASTM D 2671
|
No cracking
|
|
Voltage withstand (AC 2500V, 60 seconds)
|
ASTM D 2671
|
No breakdown
|
|
Volume resistance
|
ASTM D 876
|
1014Ω.cm(min.)
|
|
Flammability
|
SAE-AMS-DTL-23053/5
|
Self-extinguish in 30 sec.
|
|
Copper corrosion(158℃,168hrs.)
|
UL 224
|
Pass
|
|
Water absorption
|
ASTM D 570
|
<0.5%
|
