Excellent tensile strength solder ring wire splice heat shrinkable tubing BH-STT
- Applications: BH-STT excellent tensile strength solder ring wire splice heat shrinkable tubing, one piece design, it consists of translucent improved polyolefine heat shrinkable tubing and fluxed solder.Provides insulation, inspection, strain relief and is waterproof.The color tube appear a proper wire size and makes installation easy and lowers the installed cost.
-
Characteristics: Shrink ratio 3:1;
Waterproof wiring splices;
Translucent tubing provides precise inspection, easy control soldering process. -
Operating temperature range: Operating temperature range: -55°C--- +125°C;
Fully recover temperature: +130°C;
Staring melt temperature of solder : +125°C;
fully melt temperature of solder: +150°C; - Approvals / Specifications: RoHS
- Colors: Red, Yellow, Blue, White, Other colors available on request
Part Number
Product Dimensions
Solder Ring Size(mm)
Max. Bundle
Standard Color
ID(±0.1mm)
L(Max)
ID(±0.1mm)
W.T(±0.05mm)
BH-STT-17
4.0
23
1.7
0.5
1.7
White
BH-STT-27
4.7
23
2.7
0.5
2.7
Red
BH-STT-45
5.7
40
4.5
0.55
4.5
Blue
BH-STT-60
6.7
40
6.0
0.60
6.0
Yellow
Dia.(mm )
