Medical grade high shrink ratio 4:1 heat shrink tubing BH-MT-2-X
- Applications: BH-MT-2-X is a high shrink ratio (4:1 or more higher) non-flame retardant heat shrink tubing made of medical grade polyolefin, and satisfies the demand of thin wall and smooth properties which invasive devices required for surgery. The excellent electrical insulation property makes it can be used in the insulation protection of electrosurgical instruments, it’s the heat shrinkable tubing that widely used in medical devices.
- Characteristics: Flexible; variety of colors Excellent electrical insulation properties
-
Operating temperature range: Minimum shrink temperature: 80℃;
Minimum shrink temperature: 110℃; -
Approvals / Specifications: ISO 10993-1 compliant
Compatibility with gamma rays and ETO sterilization - Colors: Black, Transparent
|
Model |
Supplied ID (mm) |
Fully Recovered (mm) |
|
|
ID |
Wall Thickness |
||
|
BH-MT-2-X-4.8 |
5.20±0.30 |
<1.20mm |
0.51±0.08 |
|
BH-MT-2-X-6.4 |
7.00±0.30 |
<1.60mm |
0.51±0.08 |
|
BH-MT-2-X-9.5 |
10.00±0.30 |
<2.40mm |
0.51±0.08 |
|
BH-MT-2-X-12.7 |
13.50±0.40 |
<3.20mm |
0.64±0.08 |
Other sizes are available on request.
Cross Reference：Tyco-Raychem MT-6000
|
Property |
Test Method |
Typical Data |
|
Longitudinal change % |
ASTM D 2671 |
-10~+5 |
|
Tensile strength/MPa |
ASTM D 638 |
≥10.4 |
|
Elongation at break/% |
ASTM D 638 |
≥200 |
|
Low temperature flexibility(-55°C/4h) |
ASTM D2671 |
No cracking |
|
Heat shock(180˚C/4 h) |
ASTM D2671 |
No cracking |
|
Dielectric strength/kV/mm |
ASTM D 2671 |
≥15 |
|
Volume resistivity/Ω·cm |
ASTM D 876 |
≥1015 |
|
Water absorption（%）（23℃、24h） |
ASTM D 2671 B |
≤0.4 |
