热缩电缆终端头1-36KV BH-HTK
-
产品应用:
BH-HTK 热缩缩电缆终端可用于室内和室外的应用单芯和三芯电缆1kV直到36kV的终端安装。
-
产品特性:
安装简单快捷,不需要额外的工具,紧密密封,高回弹即使经过长年老化和暴露。
-
操作温度:
最小完全收缩温度: 120℃ -
认证及标准:
RoHS
- 颜色: 红色
电压范围 U0/U (Um) |
芯数 |
电缆截面积/mm2 |
产品型号 |
|
户内终端 |
户外终端 |
|||
18/30kV(36) |
3,1 |
35-50 |
18/30kV BH-HTI-3/1(1/1) |
18/30kV BH-HTO-3/1(1/1) |
70-120 |
18/30kV BH-HTI-3/2(1/2) |
18/30kV BH-HTO-3/2(1/2) |
||
150-240 |
18/30kV BH-HTI-3/3(1/3) |
18/30kV BH-HTO-3/3(1/3) |
||
300-400 |
18/30kV BH-HTI-3/4(1/4) |
18/30kV BH-HTO-3/4(1/4) |
||
500-630 |
18/30kV BH-HTI-3/5(1/5) |
18/30kV BH-HTO-3/5(1/5) |
||
12/20kV(24) |
3,1 |
35-50 |
12/20kV BH-HTI-3/1(1/1) |
12/20kV BH-HTO-3/1(1/1) |
70-120 |
12/20kV BH-HTI-3/2(1/2) |
12/20kV BH-HTO-3/2(1/2) |
||
150-240 |
12/20kV BH-HTI-3/3(1/3) |
12/20kV BH-HTO-3/3(1/3) |
||
300-400 |
12/20kV BH-HTI-3/4(1/4) |
12/20kV BH-HTO-3/4(1/4) |
||
500-630 |
12/20kV BH-HTI-3/5(1/5) |
12/20kV BH-HTO-3/5(1/5) |
||
8.7/15kV(17.5) |
3,1 |
25-50 |
8.7/15kV BH-HTI-3/1(1/1) |
8.7/15kV BH-HTO-3/1(1/1) |
70-120 |
8.7/15kV BH-HTI-3/2(1/2) |
8.7/15kV BH-HTO-3/2(1/2) |
||
150-240 |
8.7/15kV BH-HTI-3/3(1/3) |
8.7/15kV BH-HTO-3/3(1/3) |
||
300-400 |
8.7/15kV BH-HTI-3/4(1/4) |
8.7/15kV BH-HTO-3/4(1/4) |
||
500-630 |
8.7/15kV BH-HTI-3/5(1/5) |
8.7/15kV BH-HTO-3/5(1/5) |
||
6/10kV(12) |
3,1 |
25-50 |
6/10kV BH-HTI-3/1(1/1) |
6/10kV BH-HTO-3/1(1/1) |
70-120 |
6/10kV BH-HTI-3/2(1/2) |
6/10kV BH-HTO-3/2(1/2) |
||
150-240 |
6/10kV BH-HTI-3/3(1/3) |
6/10kV BH-HTO-3/3(1/3) |
||
300-400 |
6/10kV BH-HTI-3/4(1/4) |
6/10kV BH-HTO-3/4(1/4) |
||
500-630 |
6/10kV BH-HTI-3/5(1/5) |
6/10kV BH-HT0-3/5(1/5) |
||
0.6/1kV(1.2) |
4, 5, 3, 2, 1 |
4-6 |
0.6/1kV BH-HT-4(5,3,2,1)/(-1) |
|
10-16 |
0.6/1kV BH-HT-4(5,3,2,1)/0 |
|||
25-50 |
0.6/1kV BH-HT-4(5,3,2,1)/1 |
|||
70-120 |
0.6/1kV BH-HT-4(5,3,2,1)/2 |
|||
150-240 |
0.6/1kV BH-HT-4(5,3,2,1)/3 |
|||
300-400 |
0.6/1kV BH-HT-4(5,3,2,1)/4 |
