Number and alphabet printable heat shrinkable maker tubing BH-NIT
- Applications: BH-NIT number and alphabet printable heat shrinkable maker tubing is fabricated from irradiated, thermally stabilized and flame retarded modified polymer compound without any glues. It has two shrink ratio, 2:1 and 3:1. BH-NIT is a flexible, flame retardant printable heat-shrink tubing, with outstanding physical performance. It is designed in flattering configuration,has a good printing effect, reliable for wire and cable identification system.
-
Characteristics: Shrink ratio 2:1 and 3:1;
Flexible, flame retardant;
Resistant to abrasion and chemical;
Reliable physical, chemical and electrical;
Pre-cut tube with dotted for tearing off the tube easily. -
Operating temperature range: Operating temperature range: -40°C--- +125°C;
Maximum storage temperature: +50°C -
Approvals / Specifications: Product is compliant to EU RoHS, Directive 2002/95/EC.
Meet UL224 E25532 125°C VW-1,AMS-DTL-23053/5 class 1; SAE-AS81531,MIL-STD-202 - Colors: Yellow, White, Other colors available on request
Heat shink ratio 2:1 Heat shink ratio 3:1 Printing contents and other size could be custom on request. Property States Typical data Test method Tensile strength (MPa) unaged ≥10.4 ASTM D2673 heat-aged ≥7.3 Ultimate elongation (%) unaged ≥200 heat-aged ≥100 Voltage withstand(V) unaged 2500V,60s,Pass UL224 Dielectric strength (MV/m) unaged ≥15 IEC 60243 Volume resistivity (Ω-cm) unaged ≥1014 IEC 60093 Water absorption (%) Unaged ≤1.0 ASTM D 570 Corrosion Unaged Pass UL 224 Heat shock Unaged No cracks, flowing or dripping UL 224 Low temperature flexibility Unaged No cracks UL 224
Part No.
Supplied ID（mm）
After recovery(mm）
Package
ID
Wall Thickness
m/roll
BH-NIT-2X-2.4
3.0±0.2
≤1.3
0.45±0.10
50
BH-NIT-2X-3.2
3.5±0.2
≤1.5
0.45±0.10
50
BH-NIT-2X-4.8
5.0±0.2
≤2.3
0.45±0.10
100
BH-NIT-2X-6.4
6.5±0.2
≤3.0
0.56±0.10
100
BH-NIT-2X-9.5
10.5±0.3
≤5.0
0.56±0.10
100
BH-NIT-2X-12.7
12.5±0.3
≤6.0
0.56±0.10
100
BH-NIT-2X-19
19.0±0.5
≤9.0
0.70±0.10
100
BH-NIT-2X-25
26.0±0.5
≤12.5
0.90±0.15
50
BH-NIT-2X-38
41.5±1.0
≤20.0
1.00±0.15
50
Part No.
Supplied ID（mm）
After recovery(mm）
Package
ID
Wall Thickness
m/roll
BH-NIT-3X-2.4
≥2.4
≤0.8
0.55±0.10
50
BH-NIT-3X-3.2
≥3
≤1
0.55±0.10
50
BH-NIT-3X-4.8
≥4.5
≤1.5
0.60±0.10
100
BH-NIT-3X-6.4
≥6
≤2
0.60±0.10
100
BH-NIT-3X-9.5
≥9
≤3
0.75±0.10
100
BH-NIT-3X-12.7
≥12
≤4
0.75±0.10
100
BH-NIT-3X-19
≥18
≤6
0.85±0.10
100
BH-NIT-3X-25
≥24
≤8
1.00±0.20
50
BH-NIT-3X-38
≥39
≤13
1.50±0.20
50
