Normal size(mm)
|
As supplied (mm)
|
After recovered (mm)
|
Standard length
(m/spool)
|
|
Inside diameter(Min.)
|
Inside diameter(Max.)
|
Wall thickness
|
|
3/64
|
1.2
|
0.6
|
0.40±0.08
|
200
|
|
1/16
|
1.6
|
0.8
|
0.43±0.08
|
200
|
|
3/32
|
2.4
|
1.2
|
0.51±0.08
|
200
|
|
1/8
|
3.2
|
1.6
|
0.51±0.08
|
200
|
|
3/16
|
4.8
|
2.4
|
0.51±0.08
|
100
|
|
1/4
|
6.4
|
3.2
|
0.64±0.08
|
100
|
|
3/8
|
9.5
|
4.8
|
0.64±0.08
|
100
|
|
1/2
|
12.7
|
6.4
|
0.64±0.08
|
50
|
|
5/8
|
16.0
|
8.0
|
0.76±0.08
|
50
|
|
3/4
|
19.1
|
9.5
|
0.76±0.08
|
50
|
|
1
|
25.4
|
12.7
|
0.89±0.12
|
50
|
Special size, cut pieces are available on request.
|
Property
|
Test Method
|
Typical Data
|
|
Tensile strength
|
ASTM D 2671
|
16MPa
|
|
Elongation at break
|
ASTM D 2671
|
500%
|
|
Tensile strength after aging at 175℃for 168 hrs
|
ASTM D 2671
|
14MPa
|
|
Elongation after aging at175℃for 168 hrs.
|
ASTM D 2671
|
250%
|
|
Flammability
|
Self-extinguish in 30 sec.
|
Pass
|
|
Heat shock (250℃/ 4 hrs.)
|
ASTM D 2671
|
No cracking
|
|
Cold bend test (-55℃/ 4 hrs.)
|
ASTM D 2671
|
No cracking
|
|
Dielectric strength
|
ASTM D 150
|
20KV/mm
|
|
Volume resistance
|
ASTM D 876
|
1014 .cm
|
|
Copper Corrosion
|
UL 224
|
Pass
|
|
Water absorption
|
ASTM D 570
|
0.15%
|
|
Chemical resistance
|
SAE-AMS-DTL-23053/5
|
Pass
|
|
Longitudinal shrinkage
|
UL 224
|
5%
|
|
Eccentricity
|
UL 224
|
30%
|
